Floorplans

Floor	Sq ft	Sq m
11th floor	LET	LET
10th floor	LET	LET
9th floor	28,094	2,610
8th floor	28,091	2,610
7th floor	28,089	2,610
6th floor	LET	LET
5th floor	13,998	1,300.5
4th floor	28,051	2,606
3rd floor	28,050	2,606
2nd floor	28,026	2,604
1st floor	25,449	2,364
Ground floor	24,706	2,264

Specification

Key dimensions

• 1.5m planning grid
• 3.00m floor to ceiling

Floors and ceilings

• 150mm(nominal) raised access floor
• Powder coated perforated metal pan ceiling tiles

Air conditioning

• EC/DC 4-pipe variable air volume fan coil on the perimeter providing heating and cooling with a 2-pipe variable speed fan coil in the internal areas to provide cooling only

Mechanical services

• Internal design conditions
• 24°C +/- 2°C (Summer)
• 20°C +/- 2°C (Winter)
• Sprinklers

Electrical services

• Small power: 15w/sq m plus 10w/sq m
• Lighting: 10w/sq m – LG7 Compatible
• BMS

BLINDS AND FLOOR BOXES

• 80mm Venetian blinds
• Floor boxes provided at 1:10 per sq m

Standby generators

• Landlord generator
• Tenant plant area

Population density

• Occupation of 1:10 per sq m with opportunity for 1:8 sq m on lower floors (escape 1:6 per sq m)

Lifts

• 8 No. 21 person passenger destination control
• 1 No. 2000 kg goods lift
• 1 No. 630 kg shuttle lift from undercroft to reception

Wc and shower provision

• 1:10 with no diversity or 1:8 with 20% diversity
• 19 showers provided in undercroft with opportunity for additional if required

Storage and access

• 168 bike racks plus lockers
• 18 motorcycle spaces
• 246 car spaces (93 in undercroft)

SUSTAINABILITY

• BREEAM excellent
• Automated external solar shading
• Rainwater storage
• EPC B
